Descrição do produto
- Smart Soldering
- Optimized Module Size
- Smart Module Packaging and Logistics
- Optimized Electrical Parameters
- Gallium-doped Technology
Uniform smart soldering increases the power and efficiency of the module, and improves the power load capacity. Large-format modules with M10 wafer size use dual-glass and frame packaging to ensure module strength. Smart module packaging solutions are used to achieve high reliability, low-cost transportation and logistics. The working current is about 13A, which is perfectly adapted to mainstream string inverters. Gallium-doped technology overcomes LID degradation and guarantees the long-term power generation of the module.
Parâmetros Mecânicos
Disposição | 144 (6X24) |
Junction box | Split junction box, IP68, 3 diodos |
Peso | 32.6kg |
Tamanho | 2278×1134×35mm |
Embalagem | 31 pcs./pallet 155 pcs./20GP 620 pcs./40GP |
Electrical Performance Parameters (Teste STC)
Maximum power (Pmax/W) | 545-555 |
Open-circuit voltage (Voc/V) | 49.65-49.95 |
Short circuit current (Isc/A) | 13.92-14.05 |
Peak power voltage (Vmp/V) | 41.80-42.10 |
Peak power current (Imp/A) | 13.04-13.19 |
GYCX Solar: Seu caminho para um futuro melhor
GYCX Solar é a sua porta de entrada para um ambiente mais brilhante, futuro mais sustentável. Com nossos painéis solares de última geração e qualidade imbatível, oferecemos a melhor opção para aproveitar o poder do sol. Nossa equipe honesta, preços acessíveis, e soluções abrangentes tornam a utilização da energia solar muito fácil.
Junte-se a nós hoje e aproveite o potencial ilimitado da energia solar para um amanhã mais verde.
