Product Description
Safety and Reliability / High Yields / Optimal Electricity Cost
THE SUPPORTIVE DEVICE & PLATFORM
All kinds of communication methods available
- ShineWiFi-X/ShineLan-X/Shine4G-X
- ShineMaster
Powerful free platforms for global customers
- Growatt Monitoring Platform
Input data (DC)
| Max. DC voltage (V) | 1500 |
| Start Voltage (V) | 500 |
| Nominal voltage (V) | 1080 |
| MPP voltage range (V) | 500-1500 |
| No.of MPP Trackers | 9,12,15 |
| No.of Strings per MPPTracker | 2 |
| Max. input current per MPP tracker (A) | 30 |
| Max. short-circuit current per MPP tracker (A) | 50 |
Output data (AC)
| AC nominal power (kW) | 185-253 |
| Max. AC apparent power (kVA) | 185-253 @30°C |
| Nominal AC voltage(range*) | 800V(640-920V) |
| AC grid frequency (range*) | 50/60Hz(45-55Hz/55-65Hz) |
| Max. output current (A) | 133.5-182.6 |
| Adjustable power factor | 0.8leading…0.8lagging |
| THDi | <3% |
| AC grid connection type | 3W+PE |
GYCX Solar: Your Path to a Brighter Future
GYCX Solar is your gateway to a brighter, more sustainable future. With our cutting-edge solar panels and unbeatable quality, we offer the best option for harnessing the power of the sun. Our honest team, affordable pricing, and comprehensive solutions make going solar a breeze.
Join us today and embrace the boundless potential of solar energy for a greener tomorrow.
